IQ7 Design Guide

6.3.2 IDE Configuration

Use the IDE Configuration menu (BIOS Menu 4) to change and/or set the configuration
of the IDE devices installed in the system.
Main Advanced PCIPNP
IDE Configuration
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
Onboard PCI IDE Controller
> Primary IDE Master
> Primary IDE Slave
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.

BIOS Menu 4: IDE Configuration

Onboard PCI IDE Controller [Primary]
Use the Onboard PCI IDE Controller to configure the IDE channel.
Primary D
Disabled
IDE Master and IDE Slave
When entering setup, BIOS auto detects the presence of IDE devices. BIOS displays the
status of the auto detected IDE devices. The following IDE devices are detected and are
shown in the IDE Configuration menu:
Primary IDE Master
Primary IDE Slave
BIOS SETUP UTILITY
Boot Security
[Primary]
: [Not Detected]
: [Not Detected]
IDE drives are enabled
EFAULT
IDE drives disabled
Chipset Exit
Options
Primary
Disabled
Select Screen
↑ ↓
Select Item
Enter Go to SubScreen
F1 General Help
F10 Save and Exit
ESC Exit
Page 79
