IQ7 Design Guide
Pin Description
75 USB_P7-
77 USB_P7+
79 USB_6_7_OC#
81 USB_P5-
83 USB_P5+
85 USB_2_3_OC#
87 USB_P3-
89 USB_P3+
91 USB_HOST_PRES#
93 USB_P1-
95 USB_P1+
97 GND
99 LVDS_A0+
101 LVDS_A0-
103 LVDS_A1+
105 LVDS_A1-
107 LVDS_A2+
109 LVDS_A2-
111 LVDS_PPEN
113 LVDS_A3+
115 LVDS_A3-
117 GND
119 LVDS_A_CLK+
121 LVDS_A_CLK-
123 LVDS_BLT_CTRL
125 LVDS_DID_DAT
127 LVDS_DID_CLK
129 RSVD
131 SDVO_BCLK+
133 SDVO_BCLK-
135 GND
137 SDVO_GREEN+
Pin Description
76 USB_P6-
78 USB_P6+
80 USB_4_5_OC#
82 USB_P4-
84 USB_P4+
86 USB_0_1_OC#
88 USB_P2-
90 USB_P2+
92 USB_HC_SEL
94 USB_P0-
96 USB_P0+
98 GND
100 LVDS_B0+
102 LVDS_B0-
104 LVDS_B1+
106 LVDS_B1-
108 LVDS_B2+
110 LVDS_B2-
112 LVDS_BLEN
114 LVDS_B3+
116 LVDS_B3-
118 GND
120 LVDS_B_CLK+
122 LVDS_B_CLK-
124 RSVD
126 LVDS_BLC_DAT
128 LVDS_BLC_CLK
130 RSVD
132 SDVO_INT+
134 SDVO_INT-
136 GND
138 SDVO_FLDSTALL+
Page 11
