IQ7 Design Guide
Pin Description
3 A_Y0+
5 A_Y1+
7 A_Y2+
9 A_CLK+
11 N/C
13 GROUND
15 B_Y0+
17 B_Y1+
19 B_Y2+
21 B_CLK+
23 N/C
25 GROUND
27 VCC
29 VCC

Table 4-10: LVDS Connector Pinouts

4.2.10 Mini USB Port

CN Label: USB_CLIENT
CN Type: Mini-USB
CN Location: See Figure 4-11
CN Pinouts: See Table 4-11
Connects to a USB host device.
Pin Description
4 A_Y0-
6 A_Y1-
8 A_Y2-
10 A_CLK-
12 N/C
14 GROUND
16 B_Y0-
18 B_Y1-
20 B_Y2-
22 B_CLK-
24 N/C
26 GROUND
28 VCC
30 VCC
Page 39
