These settings enable and disabled these devices on the IQ7 Design Guide.
SW3 Description
1-On & 2-Off PCIe x1 slot enabled & LAN2 disabled
1-Off & 2-On LAN2 enabled & PCIe x1 slot disabled
3-On & 4-Off LAN1 enabled & PCIe Mini card disabled
3-Off & 4-On PCIe Mini enabled & LAN1 disabled
Table 4-34: LAN & PCIe Enable/Disable

4.4.6 TTL Voltage Selection

Jumper Label:
Jumper Type:
Jumper Settings:
Jumper Location:
Selects the voltage of the LVDS connector.
Pin Description
1-2 3.3 V
2-3 5.0 V

Table 4-35: LVDS Voltage Selection

4.4.7 SATA & Graphics Settings
Jumper Label:
Jumper Type:
Jumper Settings:
Jumper Location:
These settings enable and disabled these devices on the IQ7 Design Guide.
SW4 Description
1–On & 2-Off SDVO enabled & VGA disabled
1-Off & 2-On VGA enabled & SDVO disabled
Page 66
J_VLVDS1
3-pin header
See Table 4-35
See Figure 4–29
SW4
4 switches
See Table 4-36
See Figure 4–29
