Widerstände:
7 cm Manganindraht (1,513Ω/m),
0,1Ω .........................................R223
0,1Ω/1W ................R228, R317, R417
0,33Ω ............................... R321, R421
33Ω/SMD ............................................
R120-R125 ..........................................
47Ω .................................. R300, R400
47Ω/SMD ................................... R115
100Ω ...........................................R234
150Ω ...........................................R239
270Ω ...........R206, R208, R301, R401
270Ω/SMD .......................R100-R103
330Ω ...........................................R207
470Ω/SMD ............R227, R320, R420
820Ω/SMD .................................R203
1kΩ/SMD ....................... R126, R236
2,2kΩ/SMD ..........R209, R211, R219,
R305, R306, R312, R405, R406, R412
2,7kΩ/SMD ............R117-R119, R225
3,3kΩ/SMD ................................R235
4,7kΩ ..............................................R1
4,7kΩ/SMD ..........R104, R105, R114,
R205, R222, R218, R237, R309, R409
5,6kΩ/SMD .................... R315, R415
8,2kΩ/SMD ................................R204
10kΩ ...............................................R2
10kΩ/SMD ..................... R116, R210,
R214, R220, R231, R232, R233,
R303, R304, R318,
R403, R404, R418
22kΩ/SMD ..................... R127, R128,
R307, R407
24kΩ/SMD ...................... R314, R414
27kΩ/SMD .................................R109
33kΩ/SMD ............R221, R313, R413
39kΩ/SMD .................................R217
47kΩ/SMD ...........R212, R215, R226,
R302, R319, R402, R419
82kΩ/SMD ............R213, R308, R408
100kΩ/SMD ......... R110, R111, R113,
R200­R202, R229, R230,
R311, R411
180kΩ/SMD ............................... R112
10MΩ/SMD ..........R224, R316, R416
Kondensatoren:
10pF/SMD ............ C210-C213, C304,
C305, C404, C405
18pF/SMD ....................... C105, C106
22pF/SMD ............C118, C119, C215,
C216, C302, C303, C307, C308, C402,
C403, C407, C408
820pF/SMD ..................................C29
1nF/SMD ......................... C115, C201
3,3nF/SMD ...................................C28
4,7nF/SMD .................................C202
10nF/SMD ............C217, C301, C309,
C401, C409
27nF/SMD ..................................C200
100nF/ker .....................................C23
ELVjournal 5/00
Stückliste: Akku-Lade-Center, ALC 7000 Expert
100nF/SMD .......C2-C6, C8, C9, C14,
C20-C22, C24, C26, C27, C30-C34,
C40-C44, C100-C103, C114, C116,
C203, C205-C208, C218, C310,
100nF/250V~/MP3-X2 ..................C1
220nF/SMD ................................C209
270nF ......................................... C117
470nF/SMD ................................C104
10µF/25V .......C12, C13, C107-C111,
47µF/63V ........................ C300, C400
220µF/16V ............C306, C406, C214
1000µF/16V ........................ C10, C11
2200µF/50V ...............................C204
4700µF/25V .................................C15
4700µF/50V ...................................C7
Halbleiter:
7805 ...............................................IC1
7905 ...............................................IC2
ELV00182/OTP .........................IC100
ELV00183 .................................IC101
FM24C04/SMD ........................IC102
MAX232 ...................................IC103
CD4053/SMD ...........................IC105
CD4051/SMD ...............IC107, IC108
TL072/SMD ..............................IC200
TLC274/SMD (TI) .......IC104, IC201,
BC548C ...... T100, T101, T200, T302,
BC546 ........................................ T201
BUZ272 ...................................... T202
BC337-40 T203, T205, T301, T401,
BD249C ................ T204, T304, T404
BSR52 ........................................ T206
BD242C ...........................T300, T400
P600G ...................................... D1-D4
1N4001 ... D5-D8, D205-D207, D300,
1N4148 ...... D204, D209, D302, D402
1N5400 .................................. D9-D12
LM385/2,5V ...............................D105
ZPD12/1,3W (BZY85C12) ........D208
BZW06-10B ...............................D200
BZW06-58B ........D201, D203, D301,
SB360 .........................................D202
LED, 3 mm, grün ............ D100-D103
Side­looking­lamps, grün .D110-D115
LC-Display, ALC 7000 .........LCD100
Sonstiges:
Quarz, 14,745 MHz ....................Q100
Quarz, 4,194304 MHz,
HC49U70 ................................Q101
Speicherdrossel, 40µH/3,15A .... L200
Temperatursensor, SAS965
SUB­D­Buchsenleiste, 9­polig,
Winkelprint ........................... BU100
Netzschraubklemme, 2­polig ...... KL1
C311, C410, C411 Leistungsrelais, 5 V, 1 x um .... RE200
Trafo, 45VA, 1 x 27V/1,7A ......... TR1
Trafo, 25VA, 2 x 8V/200mA,
1 x 15V/1,4A ............................ TR2
Mini-Drucktaster, B3F-4050,
1 x ein ....................... TA100-TA106
C219 Sicherung, 315 mA, träge.............. SI2
Sicherung, 400 mA, träge.............. SI1
Sicherung, 1,6 A, träge .. SI300, SI400
Sicherung, 5 A, träge ................. SI200
Schadow­Netzschalter .................... S1
1 Adapterstück
1 Verlängerungsachse
1 Druckknopf, ø 7,2 mm
5 Platinensicherungshalter (2 Hälften)
2 Sicherungs­Abdeckhauben
7 Tastknöpfe, grau, 10 mm
6 Knippingschrauben, 2,2 x 5 mm
7 Zylinderkopfschrauben, M3 x 5 mm
16 Zylinderkopfschrauben, M3 x 6 mm
2 Zylinderkopfschrauben, M3 x 12 mm
4 Zylinderkopfschrauben, M3 x 20 mm
25 Muttern, M3
15 Fächerscheiben, M3
1 Sensorschelle
IC300, IC400 3 Glimmerscheiben, TOP­66
3 Glimmerscheiben, TO­3P
T402 6 Isolierbuchsen
1 Zugentlastungsbügel
1 Netzkabel, 2-adrig, grau
2 Aderendhülsen, ø 0,75mm
T303, T403 1 Kabeldurchführungstülle,
6 x 8 x 12 x 1,5 mm
4 Telefonbuchsen, 4 mm, rot
4 Telefonbuchsen, 4 mm, schwarz
2 Lüfteraggregat-Profilhälften, LK40
1 Axial-Lüfter, 12 V (40 x 40 x 10 mm)
D303, D400, D403 1 Tube Wärmeleitpaste
2 Leitgummis
1 LCD-Rahmen
1 Display-Abdeckung
1 Reflektorscheibe
1 Diffusorfolie
1 Reflektorfolie
D401 1 Isolierplatte
2 Befestigungswinkel
12 cm Flachbandleitung, 4-adrig
60 cm flexible Leitung, ST1 x 0,75 mm2,
rot
60 cm flexible Leitung, ST1 x 0,75 mm2,
schwarz
1 Lüfterabdeckung
1 Ferritkern für Flachbandleitung
9 Lötstifte 1,3 mm
3 Stiftleisten 3polig, gerade, einreihig
TS100, 4 U-Scheiben M3
TS101, TS102
