Fault
Motor does not turn.
Motor does not turn, clean-
ing head does not turn
Cleaning head turns too
abruptly
Uneven cleaning jet

Accessories

Description
Maintenance unit for com-
pressed air (only for com-
pressed air drive)
Hole cone in PE design
Locking screw (for 1 nozzle
operation)
Compressed air filter with
automatic condensate drain
(only for compressed air
drive)
Compressed air hose (sold
by the meter)
Exhaust air silencer with oil
separator
EU Declaration of Conformity
We hereby declare that the machine de-
scribed below complies with the relevant
basic safety and health requirements of the
EU Directives, both in its basic design and
construction as well as in the version put
into circulation by us. This declaration shall
cease to be valid if the machine is modified
without our prior approval.
The undersigned act on behalf and under
the power of attorney of the company man-
agement.
CEO Head of Approbation
Authorised Documentation Representative
S. Reiser
Alfred Kärcher GmbH Co. KG
Alfred-Kärcher-Str. 28 - 40
71364 Winnenden (Germany)
Phone: +49 7195 14-0
Fax: +49 7195 14-2212
Winnenden, 2016/01/01
18
Possible cause
There is no voltage at the motor.
Thermal protection switch in the coil
has triggered.
Error current protective switch was
triggered.
No compressed air present or pres-
sure too low.
Compressed air supply line kinked. Check compressed air hoses.
Mechanical defect on:
– Coupling parts
– Drive shaft
– Gears
Cleaning head touches container
wall.
Worn drive discs cause increased
bevel play.
Destroyed gears on bevel wheels. Replace bevel wheels.
Spray nozzles clogged.
Spray nozzles damaged.
Order No.
5.957-453
Product:
6.610-020
Type:
Relevant EU Directives
2006/42/EC (+2009/127/EC)
5.132-016
2014/30/EU
5.411-061
Applied harmonized standards
EN 55014–1: 2006+A1: 2009+A2: 2011
6.414-154
EN 55014–2: 2015
EN 60204–1
EN 61000–3–2: 2014
EN 61000–3–3: 2013
6.388-192
5.957-454
on request
Product:
Type:
Relevant EU Directives
2006/42/EC (+2009/127/EC)
2014/34/EU
Applied harmonized standards
EN ISO 12100
EN 1127-1: 2011
EN 13463-1: 2009
EN 13463-5: 2011
Applied national standards
-
ID no. of notified body
0123
TÜV SÜD
Ridlerstr. 65
80339 München
Test report no.
Ex5 0307 10088 097
Marking
II 1/2 G c T4 X +2 °C < Ta < +40 °C
II 1/3 D c T 120 °C X +2 °C < Ta <
+40 °C
Troubleshooting
Remedy
Check fuse and cables.
Fix cause for overload.
Remove cause and reset error current protective
switch.
Check compressed air supply.
Check parts and replace defective parts.
Change position of cleaning head and make sure
it can run smoothly.
Replace drive discs.
Clean spray nozzles.
Replace spray nozzles.
HKF 50 E
Internal cleaner
HKF 50 E
HKF 50 P
Internal cleaner
HKF 50 P
8
-
EN
of whom
Electricians
Electricians
Electricians
Operator
Operator
Customer Service
Operator
Customer Service
Customer Service
Operator
Operator

Warranty

The warranty terms published by our com-
petent sales company are applicable in
each country. We will repair potential fail-
ures of the appliance within the warranty
period free of charge, provided that such
failure is caused by faulty material or de-
fects in fabrication.
