KEY TO SYMBOLS AND
OUTSIDE CONTROLS
SYMBOLS
1 0 ÷ 23 Time scale in the pro-
gram graph.
Flashing of the cursor
indicates
the
coinciding with the
time on the clock.
2 T1÷T3 Temperature levels.
3
Digital thermometer.
4
Digital clock.
5
The appearance of this
message indicated that
the batteries are flat.
1÷7
6
Day of the week.
7
Standby mode.
8
WILD CARD program.
9
COOLING program.
10
HEATING program.
11
Antifreeze function.
ON
12
Thermostat enabled.
13
Time bands when the
heating/cooling plant
operates.
Red = comfort
Blue = energy saving
CONTROLS
, figure 1
14
15
hour
16
17
18
INSIDE CONTROLS
(see fig. 1)
The inside controls are accessible
when the front panel is open, as
illustrated in figure 2.
19 R
20
21 T
Selects MANUAL or
AUTOMATIC thermo-
stat mode.
D o w n / B a c k w a r d s
(temperature,
day,
hour, etc.).
Up/forwards (tempera-
ture, day, hour, etc.).
Multi-function button.
Disables
thermostat
control of the plant.
Reset button.
Clock setting.
For programming the
temperature levels (T1
to T3) and the tempe-
rature threshold, and
for viewing he tempe-
rature levels.
O N
D O
S A
V E
G I
M E
M A
L U
2 0
1 6
C
1 2
8
T 3
4
T 2
T 1
0
T
Fig. 2
22
For selecting the COO-
LING program (
the HEATING program
(
).
23
0÷23 Moves the time in the
daily program graph
backwards.
24 0÷23
Moves the time in the
daily program graph
forwards.
25 1÷7
Selects the day of the
week.
26 C
Copy program.
GB
1
0
2 3
L U
D O
R
) or
7
