6 Quick installation guide for ACSM1-04 drive modules
Figure A: The components of the standard unit.
Item Description
A Drive module
1 Lifting lugs
2 Fastening bracket
3 Input cable connection busbars and UDC+ and UDC- busbars
4 Circuit board compartment
5 Power supply and fiber optic cables to be connected to the external control unit
6 Output cable connection busbars and brake resistor connection busbars
7 PE terminal
8 Control cable duct
EN
9 Main cooling fans
10 Pedestal
11 Retractable support legs
DE
12 Base fastening screws
13 Handle for pulling the drive module out of the cabinet
14 Pedestal guide plate
ES
15 Telescopic extraction and insertion ramp
16 Top guide plate
FI
17 Optional common mode filter (+E208)
18 Grounding busbar for optional output cabling panel (+H381)
B Control unit (JCU)
FR
1 Control unit
2 Control cable clamp plate
IT
Figure B: The components of the drive module with options +H381 (power cabling panel)
and +J400 (Control unit with control panel)
NL
Item Description
A Drive module
1 Input power cabling panel (4) fastened to the drive module
RU
2 Output power cabling panel (6) fastened to the drive module
3 With option +P905, the control panel is placed in the drive module.
SV
4 Input power cabling panel (+H381)
5 Side guides (+H381)
6 Output power cabling panel (+H381).
TR
7 Rubber grommet (+H381)
B Control unit
Control unit with control panel (+J400)
ZH
Figure C: Drive module mounting into a cabinet. See the Hardware manual for the
necessary planning instructions and mechanical arrangements.
