Relais-Schaltplan:
FG-A or FG-SYS unit
POWER
SUPPLY
24V, for ex.
FG-A or FG-SYS unit
REMOTE ALARM INDICATOR
(2 SEPARATE INDICATORS)
LEAK RELAY
CONTACT (N.O.)
LEAK
INDICATOR
REMOTE ALARM INDICATOR
(1 GENERAL INDICATOR)
LEAK RELAY
CONTACT (N.O)
POWER
SUPPLY
24V, for ex.
CABLE BREAK
RELAY CONTACT (N.O.)
POWER
SUPPLY
24V, for ex.
CABLE BREAK
RELAY CONTACT (N.O.)
27
CABLE BREAK
INDICATOR
GENERAL
INDICATOR
