Technical Data - Dräger Interlock 5000 Installationsanweisung

5

Technical data

Measuring principle
Measuring range
Ambient conditions
for operation and storage
Sensitivity drift
Display
Calibration interval
Dimensions (H x W x D)
Handset
Control unit
Weight
Interlock 5000 handset
Interlock 7000 handset
Control unit
Voltage supply
Dräger Interlock 5000/7000
Electrochemical DrägerSensor
up to 2.50 mg/l
–45 °C to 85 °C
20 % to 98 % r. h.
600 to 1100 hPa
No influence of changes in altitude on
the measurement result
Typically 1 % of measured value /
month
Display
Typically 12 months
approx. 140 mm x 60 mm x 36 mm
approx. 150 mm x 90 mm x 32 mm
approx. 170 g
approx. 180 g
approx. 195 g
12 V to 24 V
Power consumption
maximum
stand-by
Switch relay for the lead
for the starter relay
Output relay
switchable de-energized
switchable energized
Ignition lead
Waiting time to be ready for
measurement
20 °C
0 °C
–25 °C
–45 °C
Technical data
<2.5 A
<1 mA
<16 A, continuous
<40 A, peak
48 V
24 V
5 V to 48 V
Interlock 5000 Interlock 7000
7 s 2 s
15 s <5 s
<60 s <60 s
<115 s 110 s
33
