Markers
1
2
44
3
Fig 35
4
Fig 36
5
Aps230 ADVANCED PersonalScope
THE SIGNAL MARKERS
The user can perform measurements on a
certain signal by using the six moveable mar-
kers. This can be useful when measuring the
interval between two points or the amplitude of
any given peak.
The following indications will appear on the
screen
(depending on screen mode):
1. The time interval between two vertical mar-
kers.
2. The calculated frequency 1/∆t.
3. The voltage between two horizontal markers
(Channel 1).
4. The voltage between two horizontal markers
(Channel 2).
5. Small dots indicating relative marker posi-
tion on the complete signal.
The markers can be moved with the arrow
keys. Keeping the key pressed will move the
marker quickly, pressing it briefly will move the
marker by 1 position. The "marker 1-2" key is
used to select the desired marker.
TM
