Screen
1
6
7
2
REMARK: The screen depends on selected layout. See page 26
OPMERKING : De schermuitlezing is afhankelijk van de gekozen weergave. Zie pag. 27
REMARQUE : l'écran dépend de la présentation choisie. Voir page 27
BEMERKUNG : Die Schirmanzeige hängt von der gewählten Wiedergabe ab. Siehe Seite 27.
24
Fig 10
Fig 11
Aps230 ADVANCED PersonalScope
Channel 1:
5
1. Measurement readout (maximum 4 at a
time). Depending on screen layout, See
10
page 26
2. Trigger information or screen hold indica-
tion.
3. Input coupling & probe setup indication
(X1 or X10).
8
4. Volts/div.
5. Time/div.
3
Channel 2:
6. Measurement readout (maximum 4 at a
4
time). Depending on screen layout, See
page 26.
7. Trigger information or screen hold indica-
tion.
9
8. Input coupling & probe setup indication
(X1 or X10).
9. Volts/div.
10. Current function controlled by cursor keys.
