Meter readout
Fig 23
Fig 25
32
Fig 22
CH1
CH2
Aps230 ADVANCED PersonalScope
Use the 'meter' key (fig. 22) to select the
desired readouts.
Setting up the measurement readouts
'channel 1':
1. Pressing the 'meter'-key selects the first
2. Press the cursorkeys to highlight the desired
3. Pressing the 'meter'-key selects the second
4. Press the cursorkeys to highlight the desired
5. Pressing the 'meter'-key selects the third
6. Press the cursorkeys to highlight the desired
7. Pressing the 'meter'-key selects the fourth
Fig 24
8. Press the cursorkeys to highlight the desired
9. Pressing the 'meter'-key returns to scope
Fig 26

READOUT SET-UP

readout location.
readout function for meter 1 readout. (Fig. 23)
readout location
readout function for meter 2 readout. (Fig. 24)
readout location
readout function for meter 3 readout. (Fig. 25)
readout location.
readout function for meter 4 readout. (Fig. 26)
mode.
Remark : Certain screen layoutsfeature
less readouts.
Follow the same procedure for Channel 2.
