Phase Sequence Test
Figure 5.8.3: Connection for phase sequence test di-
rectly to the system
The exterior conductors and the phase sequence
are directly displayed. Please refer to Figure 5.8.4
through Figure 5.8.6.
Figure 5.8.4: Display for clockwise phase sequence
Figure 5.8.5: Display for anticlockwise phase se-
quence
30
Figure 5.8.6: Display for missing exterior conduc-
tor L1
