Connecting To Earth; Operation - Scheppach 5906205901 Originalbetriebsanleitung

7.3 Assembly
Take the measuring jug out of the tank (Fig. 3a) and fit into the recess on the bottom of the tank
cover (Figure 3b).
3a 3b
Use on both sides 1 screw and 1 washer (9) to fast the carry handle (2) onto the tank (Fig.3)
3c 4
9

7.4 Connecting to earth

The housing is allowed to be connected to earth in order to discharge static electricity. To do
this, connect one end of a cable to the earth connection on the generator (Fig. 4) and the other
end to an external earth (for example an earthing rod).

8. Operation

Important! Before using the appliance for the first time the tank must be filled with a petrol mix-
ture in a mixing ratio of 1:40. To do so, use the measuring jug inside the tank (Fig. 3b) (Impor-
tant: One increment of the scale equals 20 ml). Shake the petrol mixture before filling into the
tank.
GB 45
