Important Information
Environmental Requirements
Storage and shipping
Humidity
Connection Options on the Basic Unit
VoIP internal/external,
PC and LAN
Printer or storage
medium
ISDN internal/external
Analogue internal
Connection Options on the COMpact 2BRI Module
ISDN internal/external
Connection Options on the COMpact 2FXO Module
Analogue external
Internal Analogue Port
Connection unit
Type of dialling
Open-circuit voltage
Loop current
Range
Call voltage
Audible signals
Impedances
26
-20 to +70° Celsius
10 to 90 %, non-condensing
1 Ethernet port
1 USB host port
4 ISDN ports, optionally switchable as an external S
port, internal S port and internal U
0
8 ports
2 ISDN ports with 2 RJ-45 sockets each, optionally
switchable as an external S
and internal U port (jumper)
P0
2 external analogue ports
Spring clamp connection (2-core)
Pulse or tone dialling
Max. 40 VDC
Approx. 23 mA
2 x 50 Ohm, approx. 800 m at 0.6 mm diameter
Approx. 45 V , configurable: 25/50 Hz
eff
425 Hz +/-5 %, interval +/-10 %
Symmetrical
COMpact 4000 - Firmware V6.4 - Setup V02 07/2015
port (jumper)
P0
port, internal S port
0 0
