Dimplex LA 9S-TU Montage- Und Gebrauchsanweisung Seite 27

7 Complies with the European safety regulations
8 Additional model features
8.1 Type of defrosting
8.2 Frost protection, condensate tray /
Water in device protected against freezing
8.3 Maximum operating pressure (heat sink)
2
9 Heat output COP
9.1 Heat output / COP
level
1. For air temperatures between -22°C and -5°C, flow temperature increasing from 45? to 60?.
2. These data indicate the size and capacity of the system according to EN 14511. For an analysis of the economic and energy efficiency of the system, other parameters, in particular
the defrosting capacity and regulation, should also be taken into consideration. These figures are only achieved with clean heat exchangers. Instructions for care, commissioning
and operation can be found in the relevant sections of the installation and operation instructions. The specified values have the following meaning, e.g. A7/W35: outside air tem-
perature 7 °C and heating water flow temperature 35 °C.
3. The heat output and COP is reduced by approx. 5 % in lower operation
4. When the optional weather protection hood (accessory) is used, the sound pressure level in outlet direction is reduced by 3 dB(A).
5. The specified sound pressure level represents the free sound area level. The measured value can deviate by up to 16 dB(A), depending on the installation location.
6. See CE declaration of conformity
7. The heat circulating pump and the heat pump manager must always be ready for operation.
8. The coefficient of performance (COP) in partial load operation can be increased by selecting "energy-optimised heating operation" (natural defrosting)
1 Type and order code
2 Design
Heat source
2.1 Model
2.2 Controller
2.3 Installation location
2.4 Thermal energy metering
2.5 Performance levels
3 Operating limits
3.1 Heating water flow / return
1
3.2 Air (heating)
3.2 Cooling water flow
3.3 Air (cooling)
2
4 Flow / sound
4.1 Heating water flow / internal pressure differential
Nominal flow in accordance with EN 14511at A7 / W35...30m³/h / Pa
4.2 Minimum heating water flow rate
Minimum heating water flow rate
4.3 Cooling water flow rate / internal pressure differential
Nominal flow in accordance with EN 14511A35 / W18...23 m³/h / Pa
Minimum cooling water flow rate
4.4 Sound power level according to EN 12102
Normal operation / reduced operation
4.5 Sound pressure level at a distance of 10 m (air outlet side)
Normal operation / reduced operation
4.6 Air flow
Normal operation / reduced operation
www.dimplex.de
7
bar
Performance
at A-7 / W35 kW / ---
at A2 / W35 kW / ---
at A7 / W35 kW / ---
at A7 / W45 kW / ---
at A7 / W55 kW / ---
at A10 / W35 kW / ---
1
°C
°C
°C
°C
at A7 / W45...40 m³/h / Pa
at A7 / W55...47 m³/h / Pa
return <30°C m³/h / Pa
return >30 °C m³/h / Pa
m³/h / Pa
3 4
dB(A)
5
3 4
dB(A)
4
m³/h
452168.66.01 · FD 9503
LA 9S-TU(R) - LA 12S-TU(R)
6
Reverse circulation
Yes
3.0
EN 14511
1 2
5.5 / 3,2 ---
7,2 / 4,2 ---
9,5 / 4,0 (4,2)
8,4 / 4,8 ---
8,0 / 3,6 ---
7,7 / 2,9 ---
8,8 / 5,1 ---
LA 9S-TUR
Air
Reversible
WPM Econ 5SR, wall-mounted
Outdoors
Integrated
1
up to 60 ± 2 / from 18
-22 to +35
+7 to +20
+15 to +45
1,5 / 9900
1,4 / 8800
0,9 / 3600
1,2 / 6400
0,9 / 3600
1,2 / 6400
1,2 / 6400
57 / 53
28 / 25
2700 / 2100
6
Reverse circulation
Yes
3.0
EN 14511
1 2
7,3 / 3,1 ---
8
---
11,3 / 4,7 ---
10,8 / 3,8 ---
10,0 / 3,0 ---
12,0 / 5,0 ---
LA 12S-TUR
Air
Reversible
WPM Econ 5SR, wall-mounted
Outdoors
Integrated
1
up to 60 ± 2 / from 18
-22 to +35
+7 to +20
+15 to +45
1,9 / 17800
1,8 / 16800
1,2 / 6100
1,4 / 10000
1,2 / 6100
1,4 / 10000
1,4 / 10000
58 / 54
29 / 26
4700 / 3600
EN-11
