5. Bottom band wheel
6. Housing doors
6a. Door lock
6b. Safety switch
7. On/off switch
8. Main frame
8a. Foot
8b. Suction port
9. Graduated scale (pivot range)
9a. Wing nut
9b. Locking handle
9c. Clamping plate
10. Saw band
11. Mitre gauge
11a. knurled nut
12. Parallel stop
12a. Clamping bar
13. Push stick
13a. Push rod retainer
14. Top support bearing
14a. Allen screw
15. Top guide pins
15a. Allen screws
16. Top retainer
16a. Allen screw (2x)
17. Bottom support bearing
17a. Allen screw
18. Bottom retainer
18a. Allen screw
19. Bottom guide pins
19a. Allen screws
20. Slotted screwdriver
21. Open-ended spanner, size 10/13
22. Allen key, 3 mm
23. Allen key, 4 mm
24. Allen key, 5 mm
3 Scope of delivery (Fig. 1-3)
Item Quantity Designation
4. 1 x Saw table
10. 1 x Band saw blade (pre-assembled)
12. 1 x Parallel stop
13. 1 x Push stick
20. 1 x Slotted screwdriver
21. 1 x Open-ended spanner, size 10/13
22. 1 x Allen key, 3 mm
23. 1 x Allen key, 4 mm
24. 1 x Allen key, 5 mm
1 x Band saw
1 x Operating manual
4 Proper use
The band saw is used for the longitudinal and transverse
cutting of timbers or wood-like workpieces. Round materi-
als may only be cut using suitable holding devices.
WARNING
Do not use the product to cut materials other than those
described in the operating manual.
WARNING
The supplied band saw blade is only intended for the
sawing of wood! Do not use this blade for sawing fire-
wood!
24 | GB
The product may only be used in the intended manner.
Any use beyond this is improper. The user/operator, not
the manufacturer, is responsible for damages or injuries
of any type resulting from this.
Only suitable band saw blades may be used for the prod-
uct.
An element of the intended use is also the observance of
the safety instructions, as well as the assembly instruc-
tions and operating information in the operating manual.
Persons who operate and maintain the product must be
familiar with the manual and must be informed about po-
tential dangers.
The liability of the manufacturer and resulting damages
are excluded in the event of modifications of the product.
Please note that our products were not designed with the
intention of use for commercial or industrial purposes. We
assume no guarantee if the product is used in commercial
or industrial applications, or for equivalent work.
Explanation of the signal words in
the operating manual
DANGER
Signal word to indicate an imminently haz-
ardous situation which, if not avoided, will re-
sult in death or serious injury.
WARNING
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in death or serious injury.
CAUTION
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in minor or moderate injury.
ATTENTION
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in product or property damage.
5 Safety instructions
General power tool safety warnings
WARNING
Read all safety warnings, instructions, illus-
trations and specifications provided with this
power tool.
Failure to follow all instructions listed below may result
in electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
