Table of contents
1 Introduction ........................................................
2 Product description (Fig. 1-19)...........................
3 Scope of delivery (Fig. 1-3) ................................
4 Proper use..........................................................
5 Safety instructions..............................................
6 Technical data....................................................
7 Unpacking ..........................................................
8 Assembly............................................................
9 Operation ...........................................................
10 Working instructions...........................................
11 Cleaning and maintenance ................................
12 Storage and transport ........................................
13 Electrical connection ..........................................
14 Repair and ordering spare parts ........................
15 Disposal and recycling .......................................
16 Troubleshooting .................................................
17 EU Declaration of Conformity.............................
18 Exploded view .................................................... 135
Explanation of the symbols on the
product
Symbols are used in this manual to draw your attention to
potential hazards. The safety symbols and the accompa-
nying explanations must be fully understood. The warn-
ings themselves will not rectify a hazard and cannot re-
place proper accident prevention measures.
Attention! Failure to observe the safety signs
and warning information affixed to the prod-
uct and failure to observe the safety and op-
erating manual can result in serious injury or
even death.
Before commissioning, read and observe
the operating manual and safety instruc-
tions!
Wear safety goggles.
Wear hearing protection.
If dust builds up, wear respiratory protection!
Wear safety gloves!
Always pull out the mains plug, before open-
ing the housing doors.
23
23
24
24
24
27
27
28
30
31
32
33
1 Introduction
34
Manufacturer:
34
Scheppach GmbH
34
Günzburger Straße 69
35
D-89335 Ichenhausen
36
Note:
In accordance with the applicable product liability laws,
the manufacturer of this product assumes no liability for
damage to the product or caused by the product arising
from:
• Improper handling
• Failure to comply with the operating manual
• Repairs carried out by third parties, unauthorised spe-
cialists
• Installing and replacing non-original spare parts
• Improper use
• Failures of the electrical system due to failure to ob-
serve the national electrical requirements and regula-
tions.
Note:
The operating manual is part of the product and contain
important information for safe, proper and economical op-
eration. Please also observe the applicable national regu-
lations. Read all operating and safety instructions careful-
ly before use and only use the product as described.
Keep the manual and pass it on when you give the prod-
uct to someone else.
2 Product description (Fig. 1-19)
1. Top band wheel
1a. Clamping screw
1b. Running surfaces (band saw blade)
1c. Adjusting knob
1d. Wing nut
2. Band saw blade guard
3. Top saw band guide
3a. Wing screw
3b. Adjusting nut
4. Saw table
4a. Table inlay
4b. U-reinforcement
4c. knurled nut
4d. End stop screw
4e. Lock nut
www.scheppach.com
Attention! Pay attention to the running direc-
tion.
Only carry out maintenance, conversion, ad-
justment and cleaning work when the prod-
uct is switched off and the mains plug is dis-
connected!
The product complies with the applicable
European directives.
The product complies with the applicable
Serbian directives.
GB | 23
