Assignment of the first 12 Varyscan in line (9 channel mode / 16 bit)
Varyscan No.
DMX address

3.4 DMX protocol

Occupation of the channels in 7 channel and 9 channel mode.
7 channel mode
channel no. 1
channel no. 2
channel no. 3
channel no. 4
channel no. 5
channel no. 6
channel no. 7
channel list
channel no. 1 Pan movement 370°
channel no. 2 Tilt movement 270°
channel no. 3 gobo no. 1 beam 17mm
channel no. 4 colour no. 1 white
JB-lighting Lichtanlagentechnik GmbH Sallersteigweg 15 D-89134 Blaustein Telefon ++49(0) 07304-9617-0
16
Varyscan MICRO Plus 150HTI
1 2 3
1 10 19
Pan movement
Tilt movement
gobo + reset
colour
shutter
function
gobo rotation
gobo no. 2 stars (rotating)
gobo no. 3 bar
gobo no. 4 triple tunnel (rotating)
gobo no. 5 dotted bar
gobo no. 6 dotted tunnel (rotating)
gobo no. 7 four dots
gobo no. 8 triangle (rotating)
gobo no. 9 beam 4mm
gobo no. 10 zebra crossing (rotating)
reset
colour no. 2 red
colour no. 3 yellow
colour no. 4 magenta
colour no. 5 green
colour no. 6 amber
colour no. 7 blue
colour no. 8 cyan
colour wheel spin forward
4 5 6
28 37 46 55
9 channel mode
channel no. 1 Pan movement
channel no. 2 Tilt movement
channel no. 3 gobo + reset
channel no. 4 colour
channel no. 5 shutter
channel no. 6 function
channel no. 7 goborotation
channel no. 8 Pan fine
channel no. 9 Tilt fine
DMX 000-255
DMX 000-255
DMX 000-015
DMX 016-031
DMX 032-047
DMX 048-063
DMX 064-079
DMX 080-095
DMX 096-111
DMX 112-127
DMX 128-143
DMX 144-254
DMX 255
DMX 000-015
DMX 016-031
DMX 032-047
DMX 048-063
DMX 064-079
DMX 080-095
DMX 096-111
DMX 112-127
DMX 128-255
7 8 9 10
64 73 82
11 12
91 100
