Introduction

MANUFACTURER:
scheppach
Fabrikation von Holzbearbeitungsmaschine GmbH
Günzburger Straße 69
D-89335 Ichenhausen
NOTE:
According to the applicable product liability laws, the
manufacturer of the device does not assume liability
for damages to the product or damages caused by
the product that occurs due to:
• Improper handling,
• Non-compliance of the operating instructions,
• Repairs by third parties, not by authorized ser-
vice technicians,
• Installation and replacement of non-original
spare parts,
• Application other than specified,
• A breakdown of the electrical system that occurs
due to the non-compliance of the electric regu-
lations and VDE regulations 0100, DIN 57113 /
VDE0113.
WE RECOMMEND:
Read through the complete text in the operating
instructions before installing and commissioning the
device. The operating instructions are intended to
help the user to become familiar with the machine
and take advantage of its application possibilities
in accordance with the recommendations. The
operating instructions contain important information
on how to operate the machine safely, profession-
ally and economically, how to avoid danger, costly
repairs, reduce downtimes and how to increase reli-
ability and service life of the machine.
In addition to the safety regulations in the operating
instructions, you have to meet the applicable regula-
tions that apply for the operation of the machine
in your country. Keep the operating instructions
package with the machine at all times and store it in
a plastic cover to protect it from dirt and moisture.
Read the instruction manual each time before oper-
ating the machine and carefully follow its informa-
tion. The machine can only be operated by persons
who were instructed concerning the operation of the
machine and who are informed about the associated
dangers. The minimum age requirement must be
complied with.
In addition to the safety notes contained in the
present operating instructions and the special
regulations of your country, the generally recognized
technical rules for the operation of machines must
be observed.
20 GB
 www.scheppach.com  service@scheppach.com  +(49)-08223-4002-99  +(49)-08223-4002-58
Legend of Fig. 1
Start button
1
2 Handle
3 Locking lever
Motor
4
Saw blade
5
Moving saw blade guard
6
Base
7
8 Table insert
9 Rotary table
10 Workpiece clamp
Housing / base joint
11
Dust bag
12
Stationary saw blade guard
13
Scope of delivery
• Mitre saw
• Dust bag
• Workpiece clamp
• Tool for changing the saw blade – 6mm Allen key
• Tool for stop rail – 3mm Allen key
• 2 work piece supports
• Support stand
• 2 carbon brushes
• 2 batteries (AAA)
• Operating instructions
AC motor
Power S1
Operating mode motor
Idle speed n
0
Carbide saw blade
Number of teeth
Swiveling range
Miter cut to the left
Cutting data
width x height 90° / 90°
width x height 90° / 45°
width x height 45° / 90°
width x height - 45° / 45°
cutting speed m/min
inside Ø – suction connection mm
Protection class
Weight
Laser class
Wavelength of laser
Laser output
Laser module power
supply
Technical changes reserved!
220 - 240 V ~ / 50 Hz
1200 Watt
S6 25%* 1500 W
5000 min
-1
ø 210 x ø 30 x 2,6 mm
24
-45° / 0° / +45°
0° bis 45°
120 x 60 mm
120 x 35 mm
80 x 60 mm
80 x 35 mm
60
32
II
7,6 kg
2
650 nm
< 1 mW
2 x 1,5 V Micro
(AAA)
