2. Set the cutting width using the guide
notches (34).
For larger distances, the parallel guide
is only held by the holder with retaining
screw.
3. Tighten the retaining screw (26).
4. Make a test cut, check the cutting width
and correct the position of the parallel
guide (10) if necessary.
Checking the function of the
protective hood
Notes
• If the function of the protective hood is
faulty, do not put the device into opera-
tion and contact our Service Centre.
• CAUTION! The protective hood (17)
must not jam. When the pull lever (18) is
released, the protective hood (17) must
automatically spring back to the starting
position.
Procedure
1. Pull the pull lever (18) of the protective
hood (17) as far as it will go.

Adjusting the cutting depth

Notes
• You can infinitely adjust the cutting depth:
0 mm–53 mm
• Set the cutting depth approx. 3 mm
greater than the material thickness. This
gives you a clean cut.
• The cutting angle setting scale only ap-
plies to vertical cuts (0°). Increase the cut-
ting depth accordingly for other cutting
angles.
Procedure
1. Remove the battery (29) from the device.
2. Loosen the retaining screw (6) for the cut-
ting depth setting.
3. Set the desired cutting depth on the
scale (4). The upper edge of the reading
mark (32) shows the set value.
4. Tighten the retaining screw (6).

Bevel cutting

Notes
• You can infinitely adjust the cutting angle:
0°–45°
• There are no guide notches for angles
between 0° and 45°.
12
• The larger the cutting angle, the smaller
the maximum cutting depth.
Procedure
1. Remove the battery (29) from the device.
2. Loosen the retaining screw (23) for the
cutting angle setting.
3. Set the desired cutting angle on the scale
(22). The upper edge of the reading mark
(24) shows the set value.
4. Tighten the retaining screw (23).

External dust extraction

CAUTION! Health hazard due to dust.
Dust from hardwood can cause cancer. Con-
nect the tool to a suitable class M extraction
device.
Connecting external dust extraction
(Fig. B)
1. Connect a suitable dust extraction (not
included) to the chip ejector (20).
2. If the external dust extraction does not fit,
use the additional reducer piece (9).
Removing external dust extraction (Fig. B)
1. Remove the dust extraction from the chip
ejector (20).
2. Remove the reducer piece (9).

Checking the battery charge level

LEDs
red, orange, green
red, orange
red
1. Press the button (31) next to the charge
level indicator button (30) on the battery
(29).
The LEDs of the charge level indicator
show how much charge remains in the
battery.
2. Charge the battery (29) when only the red
LED on the charge level indicator (30) is
illuminated.

Charging the battery

See also the charger instruction manual.
Notes
• If warm, allow the battery to cool before
charging.
• Do not expose the battery to direct sun-
light for long periods and do not place it
on a radiator (max. 50°C).
Meaning
Battery charged
Battery partially
charged
Battery needs to be
charged
