EN
SPECIFICATIONS
Model NO.
NDD1908R
(824-115V70_824-115V90)
STRUCTURE AND PARTS
1.Front grill
2.Blade fasten nut
3.Blade
4.Grill fasten nut
5.Rear grill
6.Fan body
7.Top tube
8.Bottom tube
9.Base
10. Nut
ASSEMBLY INSTRUCTIONS
The fan is packaged with its grills un-attached. You must attach the grills before
operating the fan.
WARNING: Never operate the fan without its foundation and other parts. The fan
must only operate in the up-right position, and any other position will be
hazardous.
Do operate the fan only in upright position; any other position could create a
hazardous situation.
Assemble the foundation and other parts of the appliance in the following sequence:
Rated Voltage
220-240V~,50Hz
3
Rated Power
50W
