• Mark the correct position of the holes and fix the ceiling bracket using the metal anchor
screws or screws and washers suitable for the type of ceiling chosen.
• Verify that the bracket is correctly installed before hanging the fan. This plate must sup-
port the entire weight of the fan.
INSTALL ATI ON PRE PAR AT I ON
• To avoid personal injury, ensure that the location where you will hang the fan allows the
blades to be at a distance equal to or greater than 2.3 m from the ground and 70 cm from
the nearest wall or obstacle.
• Make sure the junction box is properly attached to the building structure and can support
the full weight of the fan.
MOU N TI N G B R ACKE T I NSTALL AT I ON
• Check that the ceiling where you want to mount the fan is stable and able to safely support
the weight of the fan.
• Do not fix the mounting bracket directly to ceilings less than 10 mm thick to avoid the risk
of the screw loosening and coming out.
• Mark the correct position of the holes and fix the ceiling bracket using the metal anchor
screws or screws and washers suitable for the type of ceiling chosen.
• Once the mounting bracket is installed, check that it is correctly installed before hanging
the fan. The mounting bracket must support the entire weight of the fan.
E NGL I SH
10
INSTALLATION INSTRUCTIONS
min. 70 cm
Drill the necessary holes and then secure the mounting bracket
with the wood screws and washers at the ceiling joints.
Drill holes with an 8 mm drill bit, according to the length of the
expansion screws. Next, attach the mounting bracket to the ceil-
ing using the expansion screws.
Drill the necessary holes and then fix the mounting bracket with
the special spring lever fixing screws for use in false ceilings.
min. 2.3 m
Wooden roof
Concrete roof
False ceiling
