20V CORDLESS PAINT SPRAYER
˜ Introduction
We congratulate you on the purchase
of your new product. You have chosen
a high quality product. The instructions
for use are part of the product. They
contain important information concerning
safety, use and disposal. Before using
the product, please familiarise yourself
with all of the safety information and
instructions for use. Only use the product
as described and for the specified
applications. If you pass the product on
to anyone else, please ensure that you
also pass on all the documentation with
it.
˜ Intended use
This 20V Cordless Paint Sprayer
(hereinafter "product" or "power tool")
is designed for applying paint, lacquers,
and glazes.
You can use the product to process spray
material with viscosity up to max. 70 DIN/
sec.
The product is not permitted to be used
ith easily ammable combustible
paints, lacquers or thinners.
Always use the spray materials according
to the intended use! Observe the
technical requirements of this product
(see "Technical data") when purchasing
and using accessory spray materials!
Any other use or modification of the
product are considered improper use
and can result in hazards such as death,
life-threatening injuries and damage.
The manufacturer is not liable for any
damages caused by improper use. The
product is not intended for commercial
use or for any other use.
* 1 nozzle is pre-installed
** 1 filter is pre installed
62 GB/MT
˜ Scope of delivery
WARNING!
m
The product and the packaging
u
materials are not children's toys!
Children must not play with plastic
bags, sheets and small parts!
There is a danger of choking and
suffocation
1× 20V Cordless Paint Sprayer
4× Nozzle *:
Ø 1.5 mm
Ø 1.8 mm
Ø 2.2 mm
Ø 2.6 mm
1× Viscosity measuring cup
1× Paper funnel
1× Cleaning needle
1× Cleaning brush
2× Filter **
1× Carrying case
1× Operating instructions
˜ Parts description
Figure A:
Nozzle, 4x
1 ] [
Ø 1.5 mm
Ø 1.8 mm
Ø 2.2 mm
Ø 2.6 mm
Needle
[ 2 ]
Small thread
[ 3 ]
Spray unit
[ 4 ]
Align spray unit
5 ] [
Connecting tube
6 ] [
Trigger
[ 7 ]
Adjusting wheel
8 ] [
Paint container
9 ] [
Riser tube
[ ]
Large thread
[ ]
Union nut
[ ]
Nozzle head
[ ]
Figure B:
Motor unit
[ ]
Air filter
[ ]
Release button
[ ]
