Proper use

This device is only intended for the
following use:
• Inflating and deflating play, sports
and beach articles, as well as
large-volume inflatable articles
such as air mattresses, inflatable
boats, paddling pools etc...
• Filling bicycle tyres.
• Use only indoors or outdoors for
short periods.
Any other use that is not expressly
permitted in this instruction manu-
al may pose a serious hazard to the
user and result in damage to the
device. The operator or user of the
machine is responsible for any acci-
dents or personal injury and/or ma-
terial damage to third parties or their
property. The machine is intended to
be used by do-it-yourselfers. It was
not designed for heavy commercial
use. The warranty is void in the case
of commercial use. The manufacturer
is not liable for damage caused by
improper use or incorrect operation.
The device is part of the
X 20 V TEAM series and can be
operated with batteries of the
X 20 V TEAM series. Batteries of
the X 20 V TEAM series may only
be charged using chargers of the
X 20 V TEAM series.

Scope of delivery/accessories

Unpack the device and check that
everything is present.
Dispose of the packaging material
properly.
• Cordless Compressor and Air
Pump
• Hose
26
NI
• Universal adapter
• Ball needle
• Adapter for bicycle valve
• Translation of the original instruc-
tions
The rechargeable battery and
charger are not included in deliv-
ery.

Overview

The illustrations for
the device can be
found on the front and
back fold-out page.
1 Handle
2 Control panel
3 Button ➖
4 On/Off switch
5 Button ➕
6 Toggle switch
7 LC display
8 Transparent cover
9 LED button
10 LED work light
11 Battery holder
12 Lever
13 Valve connection
14 Compressed air hose
15 Air outlet
16 Hose
17 Hose adapter
18 Adapter
a – Universal adapter
b – Ball needle
c – Adapter for bicycle valve
19 Battery
20 Button Charge level indicator
