Upper module plate
Air gap: 1 mm
5 plates max. for height adjustment
Fig. 4.1 Fitting of the spacer plates with 4.7 t version
10
Centering disc
(only up to 4.7 t
max. capacity)
5 plates max. for
height adjustment
Bearing
Dummy
Mounting base
(only up to 4.7 t
max. capacity)
Cross‐bracket
(Anti‐liftoff device)
Lateral stops
MOUNTING PREPARATION
RTN/M2
