Installation

Connection

Epovac with Built-in Air Ejector
(EPOMA)
Epovac without Built-in Air
Ejector (EPOCA)
4
Epovac
Instruction Manual
Epovac does not require any special place, however, the apparatus
should not be placed in direct sunlight, as the PVC vacuum chamber
is UV sensitive.
NB As impregnation liquids like epoxy are common, the apparatus
should only be operated where ample ventilation is possible, e.g.
in a fume cupboard.
The built-in air ejector enables a vacuum of 90%. This model must
be supplied with compressed air (4.5-6 bar) by means of the hose
supplied with the apparatus:
Insert the connecting tube with fitting in the quick coupling on the
rear of the apparatus.
Shorten the hose to an adequate length.
Mount the hose on the compressor.
Connect the apparatus to a vacuum pump by means of the hose,
supplied with the apparatus:
Mount the connecting tube on the fitting on the rear of the
apparatus.
Mount the hose clip and tighten it.
Shorten the hose to an adequate length.
Mount the hose on the vacuum pump.
Take care that the hose does not have any sharp bends as these will
delay the application of resin. If a longer hose is required it is
recommended to choose a hose with a larger inside diameter, in
order to secure a sufficient flow.
