Frequency (Square)
60 Hz
600 Hz
6 kHz
60 kHz
600 kHz
10 MHz
Sensitivity:
2,0V rms min.@20% to 80% duty cycle and <100kHz
5Vrms min@20% to 80% duty cycle and > 100kHz.
Frequency (Sinusodial)
40 Hz ~ 10 kHz
Sensitiviy: 15Vrms
DC Current (DCA)
600 µA
6000 µA
60 mA
600 mA
10 A
(20A: 30 sec. max. with reduced accuracy)
AC Current (ACA)
600 µA
6000 µA
60 mA
600 mA
10 A
(20A: 30 sec. max. with reduced accuracy)
All AC current ranges are specified from 5% of range to 100% of
range
0,001 Hz
0,01 Hz
0,0001 kHz
0,001 kHz
0,01 kHz
0,001 MHz
0.01 Hz
0,01 µA
0,1 µA
0,001 mA
0,01 mA
0,001 A
0,01 µA
0,1 µA
0,001 mA
0,01 mA
0,001 A
-78-
± 1.0% + 2 dgt.
not specified
± 0.5% of reading
± 1,5% + 5 dgt.
< 1 kHz
± 2,5%
+ 5 dgt.
< 5 kHz
± 3,5%
+ 5 dgt.
Not specified
