OVERVIEW AND PART NAMES

en
5
4
3
2
1
6 7
11 12
8 9 10
13 14
LEGEND
Knob, On/Off, performance
1
level
2
Status LED
3 Hygrosensor
4 AH300 pollen filter
5 Pre-filter
6 Cover / air inlet
7
Aroma compartment*
8 Drum & cover*
9 AW200 Evaporator mat**
10
Water tank
11 Air outlet
12 A7017 Ionic Silver Stick®
13 Water base*
14 Water tank cover
15
Power supply
* Washable in the dishwasher up to
50 °C (122 °F)
** Washable in the washing machine
up to 40 °C (104 °F)
