WARNING: Whenever possible, connect

a dust extraction device designed in accord-

ance with the relevant regulations regarding

dust extraction.

Attach a suction device that conforms to applicable regula-

tions. The fan output of externally attached systems must be

at least 20 m/s +/- 2 m/s. The fan output must be measured

at the attachment point of the connection tube at which the

tool is attached but not operating.

A separate dust extraction kit is available as an accessory.

1. Attach the dust extraction tube to the nozzles; the longer

hose to the upper nozzle.

2. Join the hoses with the three-way connection.

Connection: Cross-cut and mitre position

‰ Connect one hose to the guard under the table.

‰ Connect one hose to the smaller diameter outlet and

another hose to the larger diameter outlet. Use the

respective connections.

‰ Connect the hoses to the 3-way connection.

‰ Connect the individual outlet of the 3-way connection to

the hose to the dust extractor.

Connection: Saw table position

‰ Replace the saw blade guard with the guard delivered

with the dust extraction equipment and connect the hose

from the guard under the table.

‰ Proceed as with cross-cut and mitre position.

DOUBLE SLIDING TABLE

The sliding table is for board sizes left of the saw blade of

up to 1850 mm.

Care and maintenance

Repairs to this device must be made only by Adolf WÜRTH

GmbH & Co. or by someone authorized by them.

Only original replacement parts must be used.

Safety inspection / maintenance

contract

With WÜRTHmasterSERVlCE you can arrange a regular

safety inspection and a maintenance contract. Just ask for

information.
