hole on the splinter and kickback guard (16) after the splinter
and kickback guard has been brought into table saw mode.
Fasten the upper blade guard (25) to the splinter and kickback
guard by pulling the knob (76) until the plunger pin snaps
into the guard.
WARNING: Never use your saw in table
saw mode without the blade guard correctly
installed.
Attaching and adjusting the parallel stop (À g. O)
The double-high parallel stop (26) can be used in two posi-
tions (11 or 60 mm). The parallel stop can be attached to
any side of the saw blade.
TO ATTACH THE STOP IN THE PROPER POSITION,
DO THE FOLLOWING:
‰ Loosen the knob (77).
‰ Slide the bracket from the left or right. The clamping plate
(78) engages behind the front edges of the table.
‰ Turn the knob tight (77).
‰ Check to make sure the stop is parallel to the saw blade.
‰ If adjustment is required, proceed as follows:
‰ Adjust the stop in such a way that it lies parallel to the
saw blade. Also check the distance between the saw
blade and the stop on the front and rear side of the blade.
Turn the adjustment screw in the stop's holder inward or
outward, as necessary.
The stop is installed at the factory to the right of the saw blade.
TO PREPARE THE STOP FOR USE ON THE LEFT OF
THE SAW BLADE, DO THE FOLLOWING:
‰ Loosen the knob (77).
‰ Pull the bracket (79) out and insert it at the other end.
‰ Install the stop onto the table.
‰ Turn the knob tight (77).
WARNING: Use the 11 mm proÀ le for cutting
low work pieces to length in order to allow ac-
cess between the saw blade and the stop with
the sliding rod (17).
WARNING: The back end of the stop should
be level with the front side of the splinter guard.
Converting from table saw mode to mitre saw
mode (À g. A3, D, E1, E2, L1)
‰ Remove the parallel stop (26).
‰ Turn the adjustment wheel (55) on the adjuster (23)
to achieve maximum cutting depth in mitre saw mode
(À g. E2).
36
‰ Proceed as described in the paragraph "Turning the saw
head and saw table".
‰ Loosen the locking screw (75) of the splinter and kickback
guard, and remove the splinter and kickback guard (16).
Hold the blade guard (12) À rmly (À g. L1).
‰ Lower the saw blade cover.
‰ Place the splinter and kickback guard in the storage
compartment on the saw head.
‰ Reinstall the under-table safety cover (50) (À g. D).

Before operation

‰ Install the correct saw blade. Do not use excessively worn
blades. The maximum rotation speed of the device must
not exceed that of the saw blade.
‰ Do not attempt to cut excessively small pieces.
‰ Allow the saw blade to cut freely. Avoid overloading.
‰ Allow the motor to reach full speed before sawing.
‰ Make sure all locking knobs and clamping levers are
tight.
Operation
Operating instructions
WARNING: Always abide by the safety instruc-
tions and applicable regulations.
WARNING: To reduce the risk of serious
injury, turn the power tool o and discon-
nect it from the power source before mak-
ing any adjustments or removing/À tting
attachments or accessories.
WARNING:
‰ Users in the United Kingdom must observe the
"Regulations for wood-processing machines
1974" and its amendments.
‰ Check to make sure that the material to be
sawed has been safely placed and secured.
‰ Apply light pressure only to the tool and do not
exert any side pressure on the saw blade.
‰ Never overload the tool.
Make sure that the machine is placed to satisfy your ergo-
nomic conditions in terms of table height and stability. The
machine site must be chosen so that the operator has a good
overview and enough free surrounding space around the
machine to allow handling of the work piece without any
restrictions.
To reduce e ects of vibration make sure the ambient tem-
perature is not too cold, the machine and accessories are
