IT E M S
PART
1
Loc k/U n lo ck Tab
2
Regu lator
3
G as bottle with bott le h old e r
4
Regu lato r noz zle
5
Safet y clamp
6
Flexi ble ru bb e r tu be
CO NN ECTIN G THE CY L IN DE R
This appliance is designed to operate with a cylinder with a maximum size of Ø31.8 x 58 cm.
Before starting to connect the cylinder to the device:
• Select a suitable position to install the heater. Make sure there are no flammable materials or substances nearby.
• Place the gas cylinder next to the heater. Check that the gas cylinder and regulator are in good working order. Also check
that the regulator has its seal intact. Do not use any other seal. Check that they are properly connected by pulling the regu-
lator upwards. The regulator must not be disconnected from the cylinder valve.
1. Before connecting the regulator to the cylinder valve, insert the flexible tube into the regulator nozzle. To ensure optimal
coupling, use a fixing clamp of the type usually sold with this type of tube and appropriate to its dimensions. The flexible
tube used must be approved. Make sure the flexible tube is not kinked or pinched.
2. Check that all device keys are closed, the flexible coupling tube to the regulator is correctly mounted and the locking/
unlocking tab of the regulator is in the "closed" position. Without any flame lit, remove the sealing cap from the automatic
valve. Pull the ring up and place the regulator over the cylinder valve.
3. Firmly push the hoop down. You will hear a "click" sound, this indicates that the regulator is properly assembled. You can
insert the cylinder inside the main body of the heater.
4. Once the regulator is correctly mounted on the cylinder valve, you can open the gas supply by moving the regulator locking
tab in the direction opposite to that indicated by the arrow.
5. To interrupt the gas supply, proceed in reverse.
1
Closed
8
E N GL ISH
D E SCRI P T IO N
2
Bloc ks or u nb loc ks the pass age of gas from the cyli nder to
the ap p liance.
Ensu res that the flow from the su pply to the a ppliance i s
c onstant and s afe.
Fue l c ontai ner.
Allows gas to escape from the cyli nd er to the noz zle.
They allow the secu re connection of the ru bb er tu be to the
regu lator noz zle, ensu ri ng the tightness of the i nsta llation.
Allows gas from the cyli nder to pass to the bu rner.
3
FUN CTION
4
Open
