1.
Protective mesh
2.
Glass cylinder
3.
Control knob
4.
Battery compartment
5.
Magnetic door
6.
Adjustable legs
7.
Main body
8.
Protective cover
• To use this heater you will need a standard LPG gas cylinder (propane or butane).
• The hose must be CE approved and long enough to allow installation without kinks (the length must not exceed 0.7 m). The
hose must be easily visible along its entire length for inspection after installation.
• The pressure regulator must be pre-set and CE approved, and the operating pressure appropriate for the gas cylinder used.
• The gas regulator must be approved according to EN 16129:2013 with the capacity (g/h), pressure, working temperature and
inlet + outlet connection appropriate for the destination country.
• Flexible rubber gas tubing must be approved according to 16436-1:2014 with suitable interior to match the gas circuit pipe
supports and gas regulator, pressure and working temperature.
• Be especially careful of the danger of gas leakage. This can have potential consequences such as; serious personal injury or
property damage if the leaking gas ignites in an environment where it is not controlled.
SA F E T Y MEAS URE S
• When connecting the gas pump, make sure that there are no ignition sources within a radius of at least 5 m.
• Take special care not to light open flames, smoke or turn on electrical appliances, as this could cause possible sparks.
• If necessary, make sure the hose is not kinked or subject to twists, and replace it if necessary.
• Do not obstruct the venturi openings of the cylindrical compartment.
PARTS LIST
1
2
3
4
5
6
CONNECTING THE GAS CYLINDER
7
8
E NGL ISH
7
