Table of contents
1
Introduction ........................................................
2
Product description (Fig. 1-19)...........................
3
Scope of delivery (Fig. 1) ...................................
4
Proper use..........................................................
5
Safety instructions..............................................
6
Technical data....................................................
7
Unpacking ..........................................................
8
Assembly............................................................
9
Before commissioning........................................
10 Operation ...........................................................
11 Working instructions...........................................
12 Cleaning .............................................................
13 Maintenance.......................................................
14 Storage and transport ........................................
15 Repair and ordering spare parts ........................
16 Disposal and recycling .......................................
17 Troubleshooting .................................................
18 Warranty conditions - Scheppach 20V IXES se-
ries .....................................................................
19 EU Declaration of Conformity.............................
20 Exploded view .................................................... 470
Explanation of the symbols on the
product
Symbols are used in this manual to draw your attention to
potential hazards. The safety symbols and the accompa-
nying explanations must be fully understood. The warn-
ings themselves will not rectify a hazard and cannot re-
place proper accident prevention measures.
Before commissioning, read and observe
the operating manual and safety instruc-
tions!
Attention! Failure to observe the safety signs
and warning information affixed to the prod-
uct and failure to observe the safety and op-
erating manual can result in serious injury or
even death.
Wear safety goggles.
Wear hearing protection.
Always wear a safety helmet!
Wear safety gloves!
26
26
26
26
27
30
31
31
32
33
34
36
36
38
38
39
39
40
42
91
www.scheppach.com
Wear sturdy footwear!
Wear protective clothing!
Do not expose the product to rain. The prod-
uct may only be stationed, stored and oper-
ated in dry ambient conditions.
Attention! Danger of injury from running
blades.
Make sure that other persons maintain a
sufficient safety distance. Keep unautho-
rised people away from the product.
Hurled objects and rotating parts can cause
severe injuries.
Only carry out maintenance, modification,
adjustment and cleaning work when the mo-
tor is switched off and the battery is re-
moved.
Keep your distance from other people and
electrical lines.
Open
Locked
Installation direction of the saw chain
Be very careful when handling lubricants!
Cutter bar length
Cutting length
Guaranteed sound power level of the prod-
uct.
Lithium-ion battery
The product complies with the applicable
European directives.
The product complies with the applicable
Serbian directives.
