Use-by date
Attention!
Temperature limit
Humidity limit
Store in a dry place
Fragile
Cannot be use if packaging is
damaged
Do not reuse!
Dispose of properly as used
electronic equipment!
The product satisfies the
applicable requirements
stipulated in the European
Community harmonization
regulations.
Cheyenne HAWK Pen
The product satisfies the ap-
plicable requirements stipu-
lated in legal regulations of
the United Kingdom.
3 Scope of delivery
1 Cheyenne HAWK Pen
1 HAWK Pen Tray
1 Connecting cable
1 Cable adapter (6.3 mm jack to 3.5 mm
socket)
1 Maintenance kit with replacement O-rings
1 Operating instructions
4 Product info about the
HAWK Pen
The Cheyenne HAWK Pen is a high-
performance device and is much quieter
and vibrates less than conventional
tattoo machines. It has powerful skin
piercing power and frequency.
4.1 Technical data
Nominal voltage 6 to 12.6 V DC
Power intake 4 W
Max. 2.5 A for
Start-up current
max. 200 ms
Piercing frequency 70 to 160 Hz
Stroke 3.5 mm
Needle depth 0 to 4.5 mm
Electrical connection 3.5 mm jack
Drive Precision
motor – DC
Operating mode Continuous
operation
Diameter 25.4 mm
Length 123 mm
Weight Approx. 130 g
Sound emission max. 70 dB (A)
pressure level
Total vibration max. 2.5 m/s²
