Bergstrom COMPACT 1.4 Montageanweisungen Seite 17

COMPACT 1.4
Clean the hatch surround and attach 30x25
3
EPDM seal on the outside of the ridge of the
hatch gap.
HOW TO CUT EPDM GASKET TO AVOID
4
WATER FILTRATION INTO THE CABIN
A-
Glue gasket, keeping 100 mm of protection
paper at each side.
B-
Remove the two pieces of paper.
C-
Glue by pressing both ends.
B
Gasket
Gasket
Remove
3
A
Gasket
100 mm Approx. (protection paper)
C
Gasket
17
EN
15 mm
Gasket
Cabin roof
Gasket
