˜ Fitting the cutting guard
attachment
Fig . E
m
WARNING! RISK OF INJURY!
Switch off the product and disconnect
it from the mains before making any
adjustments, performing maintenance,
cleaning and when the product is not
in use .
NOTE
u
For cut-off grinding, fit the cutting guard
[ 9a ]
attachment to the grinding guard
1 . Fit the cutting guard attachment
side on which the running direction is indicated
onto the grinding guard
2 . Push the cutting guard attachment
the grinding guard
attachment clicks into place .
˜ Removing the cutting guard
attachment
Fig . E
m
WARNING! RISK OF INJURY!
Switch off the product and disconnect
it from the mains before making any
adjustments, performing maintenance,
cleaning and when the product is not
in use .
15 ] [
1 . Push the notch on the cutting guard
9a ] [
attachment away from the grinding
[ 9 ]
guard .
2 . Remove the cutting guard attachment
the grinding guard
38 GB/IE
[ 9 ]
.
[ 9a ]
with the
9 ] [
.
9a ] [
onto
9 ] [
until the cutting guard
9a ] [
from
[ 9 ]
.
˜ Fitting the additional handle
m
CAUTION!
u
For safety reasons, this product may only
be used with the additional handle
Failure to do this can lead to serious injury .
The additional handle can be screwed onto
the left or the right depending on the job at
hand .
Depending on the method of working, tighten
o
the handle on to the handle thread on the left/
right/top of the product .
˜ Fitting/changing the grinding/
cutting disc
Fig . D
m
WARNING! RISK OF INJURY!
Switch off the product and disconnect
it from the mains before making any
adjustments, performing maintenance,
cleaning and when the product is not
in use .
Always wear protective gloves when changing
grinding disc or cutting disc . The grinding
or cutting disc is very hot after use . Allow
the grinding or cutting disc to cool down
completely before touching them .
Pay attention to the dimensions of the grinding
disc or cutting disc . The diameter of the disc
bore must fit the mounting flange without any
play . Do not use a reducer or adapter .
Check the grinding disc or cutting disc . It
should not be damaged or damp, and it should
have no cracks . Otherwise, it could break
during use and cause injuries .
NOTE
u
Use only discs which are free of dirt .
7 ] [
.
