5 ] [
Main handle
6 ] [
ON/OFF switch
7 ] [
Additional handle
8 ] [
Two-hole mounting spanner
9 ] [
Grinding guard
9a ] [
Cutting guard attachment
[ 10 ]
Spindle locking button
[ 11 ]
Screw thread (3x) for the additional handle
Fig . C
12 ] [
Locking flange
[ 13 ]
Attachment spindle
[ 14 ]
Backing flange
Fig . E
[ 15 ]
Notch
˜ Technical data
Rated voltage: 230 V∼, 50 Hz
Rated power
consumption: 1,700 W
No load speed: n
0
Thread size: M14
Protection class:
II/
(double insulation)
Cutting disc *
No load speed n : max . 12,200 min
0
Disc speed: max . 80 m/s**
Disc width: Ø 125 mm
Bore hole: Ø 22 .23 mm
Thickness: 1 .2 mm
* Included in the scope of delivery .
** The grinding disc must keep a rotational
speed of 80 m/s .
3,200–9,200 min –1
–1
Noise and vibration data
Noise measurement value determined in
accordance with EN 62841 . The A-rated noise
level of the power tool is typically as follows:
Noise emission value
Sound pressure level:
Uncertainty:
Sound power level:
Uncertainty:
m
WARNING!
Wear hearing protection!
Total vibration value
Surface grinding max .:
Cutting off max .:
Uncertainty:
NOTE
u
The declared vibration total value and the
declared noise emission value have been
measured in accordance with a standard test
method and may be used for comparing one
tool with another .
u
The declared total vibration value and the
declared noise emission value may also
be used for a preliminary assessment of
exposure .
L = 91 dB
PA
K = 3 dB
L = 99 dB
WA
K = 3 dB
A , = 7 .1 m/s 2
h AG
A , = 7 m/s 2
h CO
K = 1 .5 m/s 2
