Turning power on
1. Press the POWER button or MONITOR ON button to turn the power ON.
The Main Power switch must be in the ON position in order to power up the monitor using
the POWER button on the remote control unit or on the monitor.
Power LED
lighting pattern
Glowing blue
Blinking green*
2
Glowing amber*
(Networked
standby mode)
Blinking amber*
(Standby mode)
Glowing red
* : Time setting for auto power save is available at [POWER SAVE SETTINGS].
1
* : [POWER SAVE] is set to [ENABLE].
2
* : 90 sec if [INPUT SELECT] is set to [HDMI2] without connecting an HDMI cable to HDMI2 terminal.
3
3 min if [INPUT SELECT] is set to [USB-C].
16
E
Normal
Under any of the conditions below, no input signal has been detected by
the monitor during the period of time*
• An optional sensor unit is not connected to the REMOTE input
terminal or [HUMAN SENSING] is set to [DISABLE].
• [INPUT SELECT] is set to [HDMI2] and an HDMI cable is connected
to HDMI2 terminal.
• [SLOT POWER] is [ON] or [AUTO] then an Option Board is
connected.
• [AUTO INPUT CHANGE] is set to a setting except for [NONE].
• [USB POWER] is set to [ON].
• [SLOT POWER] is set to [ON].
• [POWER CONTROL LINK] of [CEC] is set to [ENABLE].
• [DisplayPort VERSION] is set to [1.2 MST] or [1.4 MST].
• [QUICK START] is [ENABLE].
• When 20 sec*
2
blinking green, when the monitor recognizes the LAN connection
and a certain period of time has passed without selected signal
input.
• When 3.5 min have passed without the conditions of blinking amber,
2
when a certain period of time has passed without the monitor
recognizing the LAN connection and selecting the signal input.
Turn off the monitor by the Remote control unit or the monitor button.
Status of the monitor
1
have passed without meeting the conditions of
3
POWER Button
you set:
