Pkm F7-2S Bedienungsanleitung Seite 710

M
N
O
P
11. Place the whole chimney (O + N) on the extractor hood and guide the exhaust
hose (G / for extraction mode only) to the outside (s. fig. below on the left and
s. step 13.).
12. Fix the outer chimney (N) on the appliance using 2 corresponding screws (4*8
mm): s. fig. below on the right.
Fig. similar: modifications are possible.
A
D
F
IXING BRACKET OF THE OUTER CHIMNEY
O
UTER CHIMNEY
I
NNER CHIMNEY
I
NNER CHIMNEY BRACKET
E (for extraction mode only)
XHAUST HOSE
52
S
CREWS
