Layher ZIFA Aufbau- Und Verwendungsanleitung Seite 61

11
12
13
14
15
16
1297.008
Ladder frame 75/8
aluminium.
Rungs with non-slip grooving. Height
2.0 m,
width 0.75 m, weight 8.6 kg.
1211.180 Basic tube 1.8 m
steel tube, hot-dip-galvanized.
Length 1.8 m, weight 7.7 kg.
1344.002 Access ledger 0.3
aluminium, length 0.27 m,
weight 2.9 kg.
1249.000 Ballast (10 kg)
steel, hot-dip-galvanized with
half-coupler.
1250.000 Spring clip
steel.
Weight 0.1 kg.
1205.180 Guardrail 1.8 m
aluminium.
Length 1.8 m,
weight 2.3 kg.
17
18
19
20
21
22
1206.180 Double guard-
rail 1.8 m
aluminium.
Length 1.8 m, height 0.5 m,
weight 5.8 kg.
0701.938 Beam 1.8 m
aluminium. Support elements in
tower construction kit or double
side protection.
Length 1.8 m, height 0.5 m,
weight 7.2 kg.
1208.180 Diagonal brace 2.5 m
aluminium.
Length 2.5 m,
weight 3.3 kg.
1208.195 Diagonal brace 1.95 m
aluminium.
Length 1.95 m,
weight 2.8 kg.
1209.180
Horizontal diagonal brace 1.95 m
aluminium.
Length 1.95 m, weight 3.5 kg.
1275.110 Uni distance tube
Aluminium tube with hook and
rubber foot. dia. 48.3 mm,
Length 1.1 m, weight 1.4 kg.
