Assembly of intermediate platforms
All tower models
Repeat the following assembly steps 1 to 5 several times
depending on the assembly height.
1. Fit a first 2.00 m ladder frame
2. Attach the Uni assembly hooks
frame 11 for assembly of the guardrails 16.
3. Swing the ladder frame 11
in place and secure it with spring clips.
11 and secure it using spring clips
29 and position the second ladder
with guardrails 16 upwards, fit it
4. Insert diagonal braces
arrangement is shown for the tower models (Section 4).
15 .
5. Ascend to the next level and fit additional guardrails
on the second rung above the platform area.
19 and access deck 24. The diagonal bracing
16
13
