Basic structure
Tower models 1406213 and 1406215
1. Insert the castors 1 into the mobile beams
to prevent them falling out.
2. The mobile beams 7 must be connected to one another using a basic
tube 12 .
3. Pull open the basic tower 9, firmly snap in the joints in the folding
part and fit it onto the mobile beams 7.
4. Snap in the deck 23 at the second rungs of the basic tower ladder frames
.
Basic structure
Tower models 1406214 and 1406216
12
1. Insert the castors
to prevent them falling out.
2. The mobile beams
tube
3. Pull open the basic tower 9, firmly snap in the joints in the folding
part and fit it onto the mobile beams 7.
4. Brace the basic tower by installing a guardrail
rung.
5. Snap in the access deck
frames.
7 and use bolts and nuts
6. Attach the 1.95 m diagonal brace
top and to the second rung from the bottom of the opposite ladder
frame.
7. Fit two 1.00 m ladder frames
rails
15.
1 into the mobile beam
7 must be connected to one another using a basic
12 .
24 at the top rung of the basic tower ladder
10 and connect them with two guard-
16 each per side. Secure the ladder frame joints with spring clips
7 and use bolts and nuts
16 at the bottom
20 to the second rung from the
