KNOWING YOUR ESPRESSO MACHINE
1
2
3
5 6
8
12
1 HOPPER LID: for closing the bean hopper
2 BEAN HOPPER with GRIND SIZE GRADUATION and SHUTTER: fill in max. 250 g fresh, whole coffee beans.
3 CONTROL PANEL holding the OPERATING ELEMENTS and DISPLAY
4 CONTROL DIAL: turn this knob for activating the steam function or hot water function.
5 ON/OFF BUTTON: press here to switch the espresso machine on or off.
6 GRIND BUTTON: starts or stops the grinder.
7 ESPRESSO BUTTONS press one of these buttons for selecting the desired extraction volume: 1 cup (SINGLE button) or 2 cups (DOUBLE button)
8 GRINDER OUTLET: insert the portafilter into the grinder cradle for grinding directly into the filter basket.
9 GROUP HEAD: a silicone ring ensures a good seal with the filter basket; the steam screen stops the coffee powder from getting into the
water system.
10 Swivel STEAM WAND: easily turned to the desired position for milk texturing and pouring hot water.
11 Removable DRIP TRAY including a red FILLING LEVEL INDICATOR. During the extraction cycle, place your cups on the METAL GRID
12 STORAGE TRAY : located behind the drip tray for storage of accessories and tools.
Accessories
STAINLESS STEEL MILK JUG for texturing milk
STAINLESS STEEL TAMPER for applying the required pressure to the coffee powder in the filter basket
Different FILTER BASKETS for 1 or 2 cups of espresso
CLEANING BRUSH use this tool for cleaning the grinder. The handle of the this tool may be used for removing the filter basket from the portafilter
NEEDLE TOOL with two different needles—useful for opening clogged pores of the steam wand and filter baskets.
EN
68
4
7
9
10
11
Bean Hopper - Installation Settings
RIGHT
SETTING
ATTENTION
– When installing the bean funnel, always pay attention to
the correct settings on the floor, otherwise you can damage the device or the bot-
tom of the bean hopper.
PROPERTIES OF YOUR ESPRESSO MACHINE
Your new Design Espresso Barista Pro is designed for brewing fresh, hot espresso
with only some short steps of preparation. For this purpose, the appliance is equip-
ped with the following properties and features.
• On a glance the display on the control panel provides information on the current mode
of operation and the available functions (see below: 'Display and Operating Elements').
• Via the integrated grinder you can grind whole, fresh coffee beans just before
extraction. The correct dose is given off automatically (see below: 'Adjustable,
Automatically Controlled Grinder'). The amount can be programmed according
to your likings (see: 'Entering Your Own Settings').
• Almost immediately after switching on the espresso machine you can start the grin-
der. Within approx. 1 minute, the water system is heated to operating temperature
and you can start the extraction.
• The automatically controlled espresso funktions for 1 cup (SINGLE) or 2 cups
(DOUBLE) perform a pre-injection cycle, before starting the extraction process:
When pressing an espresso button, the water system gives off a little amount
of water first for moistening the coffee powder and letting it swell. After a short
WRONG
SETTING
