Oil tank volume
Transmission
Drive wheel tyre size
Recommended tyre
pressure
Forward/reverse drive
speed
Machine dimensions
Sweeping width
Brush angle
Brush diameter
Brush speed
Weight
Max. slope angle
Subject to technical changes!
Noise and vibration
m Warning: Noise can have serious effects on your
health. If the machine noise exceeds 85 dB, please
wear suitable hearing protection.
Information about noise level measured in accord-
ance with EN ISO 3744:1995
Noise data
Sound power level L
WA
Sound pressure level L
pA
Uncertainty K
wa/pA
Vibration parameters
Vibration a
h
Uncertainty K
h
8. Unpacking
• Open the packaging and carefully remove the prod-
uct.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
0.6 litre
1 forward gear + 1 reverse
gear
3.50-4" Tubeless
2 bar (30 psi)
2.95 km/h
L x W x H: 174 cm x 72 cm
x 100 cm
70 cm
0° / -25° /+25°
35 cm
520 rpm
68 kg
10°
98.5 dB
78.5 dB
2.15 dB
4.98 m/s²
1.5 m/s²
www.scheppach.com
• Check the product and accessory parts for transport
damage. In the event of complaints the carrier must
be informed immediately. Later claims will not be
recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating manual before using for the first time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Spare parts
can be obtained from your specialist dealer.
• When ordering please provide our article number as
well as type and year of manufacture for the product.
m WARNING!
The product and the packaging material are not
children's toys! Do not let children play with plas-
tic bags, films or small parts! There is a danger of
choking or suffocating!
9.
Assembly
m Due to the heavy weight of the machine, we rec-
ommend installation by at least two people.
9.1
Assembly of snow blade and collecting con-
tainer
The assembly of the snow blade and the collection box
is described in separate installation instructions.
Place the product on a level, even surface.
Tool required:
• 2x Open-ended spanner, size 13*
• Square timbers*
*Not included in the scope of delivery!
m Place the petrol sweeper on a flat, level surface
for assembly.
9.2
Fit the lower push bar (4) (Fig. 3)
9.2.1 Remove the wheels (6)
1.
Place the product on two square timbers* approx.
20 cm high so that the wheels (6) can move freely.
Ensure that the product with the engine rests flat
on the square timbers* and cannot tip over.
2.
Remove the locking plate (6a).
3.
Remove the wheel (6) from the wheel axle.
4.
Repeat the process on the other side.
GB | 33
