10 Electrical connection
The electrical motor installed is connected and ready
for operation. The connection complies with the ap-
plicable VDE and DIN provisions. The customer's
mains connection as well as the extension cable used
must also comply with these regulations.
• The product fulfils the requirements of EN 61000-3-11
and is subject to special connection requirements.
This means that use at any freely selectable connec-
tion points is not permitted.
• The product can cause temporary voltage fluctuations
in unfavourable mains conditions.
• The product is intended exclusively for use at connec-
tion points which
a) do not exceed a maximum permitted mains imped-
ance "Z" (Zmax. = 0.471 Ω), or
b) have a continuous current carrying capacity of the
mains of at least 100 A per phase.
• As the user, you are required to ensure that the con-
nection point at which you wish to operate the product
fulfils one of the requirements mentioned, a) or b). If
necessary, consult with your energy supplier in this re-
gard.
10.1 Damaged electrical connection
cables
The insulation on electrical connection cables is often
damaged.
This may have the following causes:
• Pressure points, where connection cables are passed
through windows or doors,
• Kinks where the connection cable has been improper-
ly fastened or routed,
• Places where the connection cables have been cut
due to being driven over,
• Insulation damage due to being ripped out of the wall
socket,
• Cracks due to the insulation ageing.
Such damaged electrical connection cables must not be
used and are life-threatening due to the insulation dam-
age.
Check the electrical connection cables for damage regu-
larly. Ensure that the connection cables are disconnected
from electrical power when checking for damage.
Electrical connection cables must comply with the appli-
cable VDE and DIN provisions. Only use connection ca-
bles of the same designation.
The printing of the type designation on the connection ca-
ble is mandatory.
Safety information for replacing damaged or defective
mains connection cables
Connection type Y
If it is necessary to replace the mains connection cable,
this must be done by the manufacturer or their represen-
tative to avoid safety hazards.
22 | GB
10.2 AC motor
Connections and repair work on the electrical equipment
may only be carried out by electricians.
• The mains voltage must be 230 V - 240V~.
• Extension cables up to 25 m long must have a cross-
section of 1.5 mm².
11 Cleaning and maintenance
WARNING
Have maintenance and repair tasks that are
not described in this operating manual, car-
ried out by a specialist workshop. Use only
original spare parts.
There is a risk of accident! Always carry out
maintenance and cleaning work with the mo-
tor switched off and the mains plug discon-
nected. There is a danger of injury! Let the
Product cool down before all maintenance
and cleaning tasks. Elements of the engine
are hot. There is a danger of injury and burn-
ing!
The product can start unexpectedly and cause injuries.
– Switch off the product before all cleaning and main-
tenance work.
– Allow the product to cool down.
– Disconnect the mains plug!
Place the product on a level, even surface.
Tool required:
• Hexagon spanner (9)
• Oil filler bottle (10)
• Collection bucket*
* = may not be included in the scope of delivery!
11.1 Cleaning
WARNING
Do not spray the product with water or clean it under
running water. There is a danger of electric shock and
the product could be damaged.
• Keep protective devices, air vents and the motor
housing as free of dust and dirt as possible. Rub the
product clean with a clean cloth* or blow it off with
compressed air* at low pressure. We recommend that
you clean the product directly after every use.
• Never immerse the product in water or other liquids
for cleaning.
• Clean the product at regular intervals using a damp
cloth* and a little soft soap. Do not use any cleaning
products or solvents; they could attack the plastic
parts of the product. Make sure that no water can pen-
etrate the product interior.
• Always keep the product clean, dry and free from oil
or grease. Remove dust after each use and before
storage.
