- Breaking through the material to be machined.
- Overloading the power tool.
- Do not reach into the product when it is running.
Residual risks
The product has been built according to state-of-the-
art and the recognised technical safety rules.
However, individual residual risks can arise during
operation.
• Residual risks can be minimised if the "Safety Instruc-
tions" and the "Intended Use" together with the oper-
ating manual as a whole are observed.
• Use the product in the way that is recommended in
this operating manual. This is how to ensure that your
product provides optimum performance.
• Furthermore, despite all precautions having been met,
some non-obvious residual risks may still remain.
• Keep your hands away from the working area when
the product is in operation.
• Damage to hearing if the stipulated hearing protection
is not worn.
• Damage to the lungs if the stipulated respiratory pro-
tection is not worn.
• Risk of injury from tools thrown away due to improper
holding or guiding.
• Health hazard due to electrical power, with the use of
improper electrical connection cables.
• Avoid accidental start-up of the product: when insert-
ing the plug into the socket, do not press the on/off
switch.
• Before performing setting or maintenance work, re-
lease the on/off switch and pull out the mains plug.
WARNING
This power tool generates an electromagnetic field
during operation. This field can impair active or passive
medical implants under certain circumstances. In order
to prevent the risk of serious or deadly injuries, we rec-
ommend that persons with medical implants consult
with their physician and the manufacturer of the medical
implant prior to operating the power tool.
WARNING
In case of extended working periods, the operating per-
sonnel may suffer circulatory disturbances in their
hands (vibration white finger) due to vibrations.
Raynaud's syndrome is a vascular disease that causes
the small blood vessels on the fingers and toes to
cramp in spasms. The affected areas are no longer
supplied with sufficient blood and therefore appear ex-
tremely pale. The frequent use of vibrating products can
cause nerve damage in people whose circulation is im-
paired (e.g. smokers, diabetics).
If you notice unusual adverse effects, stop working im-
mediately and seek medical advice.
6 Technical data
Rated voltage
Rated input
Impact force
Number of impacts
Max. speed
Oil tank volume
Recommended oil
Protection class
Protection category
Retainer
Length of mains
connection cable
Weight
Subject to technical changes!
WARNING
Noise can have serious effects on your health. If the
machine noise exceeds 85 dB, please wear suitable
hearing protection for you and persons in the vicinity.
Information on noise measured according to the relevant
standards (EN 62841-1):
Noise data
Sound pressure level L
Measurement uncertainty K
Measured sound power level L
Guaranteed sound power level L
Measurement uncertainty K
Vibration parameters (hand/arm vibration)
Vibration a
Measurement uncertainty K
The total vibration emission values specified and the de-
vice emissions values specified have been measured in
accordance with a standardised test procedure and can
be used for comparison of one electric tool with another.
The total noise emission values specified and the total vi-
bration emission values specified can also be used for an
initial estimation of the load.
WARNING
The noise emission values and vibration
emission value can vary from the specified
values during the actual use of the power
tool, depending on the type and the manner
in which the electric tool is used, and in par-
ticular the type of workpiece being pro-
cessed.
Try to keep the stress as low as possible. For example:
Limit working time. In doing so, all parts of the operating
cycle must be taken into account (such as times in
which the power tool is switched off or times in which it
is switched on, but is not running under a load).
www.scheppach.com
II /
SDS-HEX System 30 mm
pA
pA
wA
wA
wA
h Cheq
230-240 V~/ 50 Hz
1900 W
60 J
1930 bpm
1930 rpm
approx. 130 ml
10W40 / 5W40
(double insulation)
IP20
3 m
15.5 kg
82.5 dB
2.35 dB
102.5 dB
105 dB
2.35 dB
2
18.568 m/s
2
1.5 m/s
