1 | General EN InsertControl montieren
Here you can see the assembly situations:
On some fireplace inserts the assembly situation can be se-
lected on either the left- or right-hand side. On some mod-
els, assembly situation is only possible on one side.
45x, 55x, 65x, 75x (1) – installation on the left
45x (2) – installation on the right
1
55x, 65x, 75x (3) – installation on the right
75x II (4) – installation on the left
75x II (5) – installation on the right
2
3
4
5
Fig. 10: Assembly situations
