Abbildung A.2 Dauerbetrieb, Überlastfehler
Hold time (variabel, depending on
the application)
Signal length depending on the
necessary weld time
Reset the overload alarm
Overload alarm during the weld
Frequency seek
Reset the frequency memory
inside the generator
Power ON (Digital Compact Pin
11,3)
Signal
Pin DCxxx
Signal direction
